As a handheld portable digital ultrasound detector, HS710 can achieve A-scan, B-scan, C-scan imaging modes, ultra high speed sampling, more accurate echo display, and more precise positioning. Remote real-time positioning, WIFI connection, and cloud detection can be achieved through a mobile app
●400MHz sampling frequency, higher waveform restoration
● Remote real-time positioning and true backup wireless network function can be achieved through mobile APP
● Resistive touch screen, oil and water resistant, touch sensitive
● Equipped with B-scan, C-scan TOFD、 Guided wave function, optional
●Innovative upgrade of UIT imaging and analysis functions
Characteristics of UIT functional modules
●Upgrade with 710 device, no need for external modules, good compatibility
●Specialized scanner, suitable for grid scanning in various modes such as pipes and plates
● Equipped with automatic setting function for scanning process parameters, UIT detection is simpler
●Laser positioning is compatible with mechanical positioning, accurate and fast in one step
● It has multiple view modes A, B, and C for easy defect recognition
● UIT dedicated offline software, defect assessment is simple and easy to operate.
Transmit Parameters
| Parameter | Specification |
|---|---|
| Pulse Type | Negative Square Wave Pulse |
| Transmit Pulse Voltage | 200V – 400V |
| Pulse Rise Time | <10 ns |
| Pulse Width | 30ns-1000ns |
| Impedance Matching | 48Ω, 500Ω |
Receive Parameters
| Parameter | Specification |
|---|---|
| Sampling Frequency / Bits | 400MHz / 10 bits |
| Sampling Depth | 512 |
| Equivalent Input Noise | <60nV/√Hz |
| Signal Bandwidth | 0.5MHz-30MHz |
| Pulse Repetition Frequency | 15Hz-1000Hz |
| Attenuator Accuracy | < ±1dB / 12dB |
| Gain Range / Step | 120dB / 0.1dB, 1dB, 2dB, 6dB (Automatic Adjustment) |
| Sound Velocity Range | (300-20000) m/s |
| Dynamic Range | ≥36dB |
| Vertical Linear Error | ≤2% |
| Horizontal Linear Error | ≤0.1% |
Comprehensive Performance
| Parameter | Specification |
|---|---|
| Resolution | >32dB |
| Sensitivity Margin | ≥65dB (Φ2×200mm) |
| Detection Mode | Full Wave Rectified, Positive Rectified, Negative Rectified, RF |
| Operating Mode | Single Crystal Inspection, Dual Crystal Inspection |
Instrument Parameters
| Parameter | Specification |
|---|---|
| Overall Dimensions | 266 × 164 × 48 (mm) |
| Overall Weight | 1.25kg (including battery) |
| Display Screen Size | 5.7″ |
| Display Resolution | 640 × 480 |
| Power Supply / Battery | DC (DC12V/3.34A); Battery 7.4V/10.2Ah |
| Battery Life | Continuous operation ≥8 hours (lithium battery power) |
| Interfaces | WIFI, USB2.0, VGA, OTG |
| Operating Temperature | (-10 – 40)°C (Reference Value) |
| Relative Humidity | (20 – 95) %RH |
